Performance based on robustness and, above all, reliability.
This machine is known as the best handheld laser welding machine for metal fabrication, offering precise and efficient welding solutions.
Handheld Fiber Laser Welding Machine HJ Series - Features & Configuration
The handheld laser gun can be used forwelding, cleaning and cutting through anintelligent controller. lt is easy to use, flexible in processing, easy to carry, small insize,low in cost and has no consumables
Welding at fast speed
Its welding speed is multiplied, about 3-10 times faster than the tradition
High-precision welding
• Precise, aesthetic welds for micro parts • Minimal grinding with smooth laser start/stop • Low heat input ensures strong, clean welds
Rich welding shapes
Realize butt, overlap, stitch, fish scale, stud, T-joint, internal, external welding, etc.
Wide range of application
Apply to carbon steel, stainless steel, AL alloy, galvanized sheet, cold-rolled sheet, titanium alloy, etc.
Handheld Fiber Laser Welding Machine HJ Seriesr With Robust, Safe, Essential
Core Performance & Structural Advantages
-
Compact handheld laser head enables micro-welding of tiny parts with high seam quality.
-
Gradual laser rise/fall at weld points avoids pits, reducing the need for grinding.
-
Low heat input minimizes deformation and undercut, ensuring strong welds.
-
Precision-focused beam delivers smooth, clean joints with minimal spatter.
-
Air-cooled laser system simplifies maintenance with no need for water chillers.
-
High-speed galvanometer scanning ensures accurate weld trajectories.
-
Integrated control and laser source design reduces footprint and wiring complexity.
-
Suitable for thin metals and complex shapes, supporting multi-angle welding.
-
Ergonomic handle and lightweight body improve operator comfort during long shifts.
-
Supports spot welding, seam welding, and stitch welding modes for flexibility.
-
Real-time display with intuitive touchscreen for quick setup and monitoring.
-
Built-in safety interlocks and alarms ensure operator protection.
-
Optional fume extraction system keeps work area clean and safe.
-
Energy-efficient laser source offers long life and low running costs.
-
Stable power output ensures consistent weld penetration and quality.
-
Compatible with automation upgrades for inline or robotic integration.
Flexibility and efficiency
Ensure safety, maximize material usage, and streamline operations for superior productivity and cost savings.
Why hwieic ?
- Ultimate dynamics and efficiency
- Durability and reliability
- Upgraded precision and accuracy
- Intelligent & ease of use
- Safety & healthy
- Versatile automation
Product Performance
With accurate control of laser beam, fast work speed and water cooling, the machine can work for a long time continuously. It has got FDA and CE certifications.
| Model | HJ-1000 | HJ-1500 | HJ-2000 | HJ-3000 |
| Laser Power | 1000w | 1500w | 2000w | 3000w |
| Operating Mode | Continuous / Modulation | |||
| Power Requirements | 220V/ 50Hz/60Hz | 380V/50Hz/60Hz | ||
| perating Temperature | 15-35℃ | |||
| Working Humidity | ＜70％ No condensation | |||
| Max. Welding Thickness | 0.5-2.5mm | 0.5-3.5mm | 0.5-4mm | 0.5-8mm |
| Welding Line Requirements | ≤0.5mm | |||
| Max. Welding Speed | 120mm/s | |||
| Machine Size | 1300*1200*800mm | |||
| Machine Weight | 200kg | |||
Product Performance
The reliable choice for lower costs with easy operation
- 4 in 1 Multifunction
- 1.5-3 [kW] Laser power
- 2 [mm] Max diameter of filler wire
- 8 [mm] Max thickness of sheet
- Relfar laser head
Tried-and-tested Structure
* Compact in size and upgrades in sheet metals, so its size is reduced by about 15%, with total footprint <0.7m2 (exclude wire feeder)
* In its design, water and electricity are separated, single-channel heat dissipation and 1-1.5mm thick metal plates are used for its main body
* Due to universal casters, it is easy to move at will for even one worker who can make it by one hand
Single-wire feeder
Wire feeding speed is adjustable from 25 to 600 cm/min in continuous and pulse mode. Its max feeding wire diameter reaches 2mm. With LCD display, it can take intelligent control of wire feeding speed.
4-in-1 laser welding head
It is equipped with 4-in-1 laser welding head permits flexible switching among welding, cutting, rust removal and weld seam cleaning. With 75 kinds of crafts, users may set up parameters by themselves when they want to try other effects.
* Run length of welding: 0-6mm
* Run length of cleaning: 0-120mm
* Run length of weld seam cleaning: 0-8mm
User-friendly design
We have given enough thought to workers’ behavioral and using habits while designing. Now, further optimization is made to make your work more convenient and easier.
* Side-attached hanger is easy to hold welding head (≤0.7kg) for workers
* Its cooling system is efficient and can enable stable output of laser beam
* Drawer-type protective lens are fast to repair and maintain and much safer
* Temperature control alarm helps to protect components from possible injury
Control System
We employ intelligent bus-based CNC system equipped with 21.5-inch touch screen. It is easy to install and debug, featuring rapid and fast data transmission, low failure rate and easy maintenance.
High Quality Results In All Sheet Thickness
HJ series laser welding machine is mainly used for welding carbon steel, stainless steel, aluminum and other metal materials.
